Caractéristiques

Feature: TRUCK CRANE

Showroom Location: Philippines, Spain, Colombia, South Africa, Malaysia

Condition: New

Rated Loading Capacity: 2 Ton

Max. Lifting Height: 7.9 m

Warranty: 1 Year

Hydraulic Cylinder Brand: Shenbai

Hydraulic Pump Brand: Shenbai

Hydraulic Valve Brand: Shenbai

Engine Brand: WEICHAI

Machinery Test Report: Provided

Video outgoing-inspection: Provided

Marketing Type: New Product 2020

Warranty of core components: 1 Year

Core Components: Pressure vessel, Motor, Bearing, Gear, Pump, Gearbox, Engine, PLC, Other

Weight (KG): 5000 kg

Product name: truck mounted crane

Crane type: folding boom

Max lifting capacity: 2 ton

max lifting height: 7.9 m

crane weight: 500kg

rotation angle: 360 )All Rotation

driving type: 4x2 4x4

fuel type: diesel

Usage: Cargo Load Telescopic Boom Lifts

Color: Customer Requirements

Informations de base

Conditions de paiement et expédition

Supply Ability: 20000 Unit/Units per Year

Description de produit

Product Description

Lorry-mounted crane is a crane actual commonly called, is a kind of hoisting machinery, is a kind of loop, intermittent movement of the machine, application is very extensive, lorry-mounted crane is mainly used for the material handling, the work is characterized by intermittent movement, which is in a working cycle, the working procedure such as picking, the shift in transport, unloading and other institutions are alternate work accordingly The truck crane is widely used in port wharf, factory workshop, construction site and other occasions that need to lift and carry materials and articles, but also used in urban construction, advertising construction, power repair, aerial work and other sites.

Specification

General	Vehicle Name	4X2 Truck mounted 2 3.2ton Crane
		Chassis Brand	FAW,Shacman,ISUZU,DONGFENG,SINOTRUK HOWO,FOTON
		Overall Dimension(mm)	599524002900
		GVW(kg)	4495
		Payload(KG)	1000
Cab	Cab Seat	Single Row or 2 row,2 or 2+3 optional
Cab		Air Conditioner	Yes
Engine	Fuel Type	Diesel
		Engie Model	4KH1CN5HS
		Engine Brand	Dongfeng
		Power(KW)	130HP
		Emmission Standard	Euro 5,6
Chassis	Drive Type	4X2
		Transmission	5-speed gearbox, Manual
		Wheelbase(mm)	3360
		Tyre Specification	7.00-16
		Tyre No.(pcs)	6+1
		Max Speed(km/h)	85
		Paint	as your required
		ABS	Yes
Superstructure	Crane	2,3.2T Crane
		Box material	Bottom 4 sides 3
		Crane type	Straight Telescopic or folding arm
		box size	2500x2000x380mm
		Optional function	1. Knuckle boom crane.
				2. Hydraulic tipper box.
				3. Box thickness according to requirement.4. Box height could be nominated
				5. Brick clamping apparatus
				6. Remote control operation
				7. Grab bucket
				8. Aerial work basket
				9. Drill
				10.Double row cab

No	Item	Data
1	max lifting capacity	2 on
2	max lifting height	7.9 m
3	working radius	5.8m
4	crane weight	500kg
5	rotation angle	360°
6	driving type	4*2
7	emission standard	EURO 3
8	fuel type	diesel

Packing & Delivery

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

Company Profile

Hubei Shenbai Special Automobile Co., Ltd. was established in 2013 and is located in Suizhou City, Hubei Province. It is a core enterprise of Shenbai Group and a strategic partner of Sany Palfinger. The group focuses on the research, development and manufacturing of cranes. CX cranes are the self-developed brand of Shenbai Automobile Group, which ranks among the best in market share and holds a number of patents. Shenbai has advanced production equipment, mature manufacturing technology, and complete testing methods. Shenbai Automobile is a forward-looking company that focuses on technological innovation, looking for opportunities to lead the future in reforms. "Innovation drives the future" is the corporate philosophy of Shenbai Group. "Rigorous, pragmatic and progressive" is the work purpose of Shenbai Group. We focus on bringing value to customers and the public by providing high-quality products and services. We continue to explore more possibilities to expand our business scope, innovate our business methods, and improve standards and respond to new market needs. Since 2017, Shenbai truck-mounted crane trucks have adopted a series of measures to maintain a high growth rate. In 2019, its domestic market share exceeded 30%, a record high. According to the current development of various market segments of cargo hoisting vehicles, the future will continue to maintain high-speed growth for a long time. The company has formed a development trend that focuses on boom-type special vehicles, withtruck mounted crane,truck cranes, wreckers with cranes, flatbed trucks, refrigerated trucks, garbage trucks,road sweeper trucks and high-altitude work vehicles at the same time. It has an annual production capacity of 20,000 special vehicles. And now we has an annual production capacity of 20,000 special vehicles. Shenbai Autombile provides incredible durability, reliability and reliable uptime, which companies all over the world rely on every day. Shenbai Automobile is equipped with more functions and capabilities, allowing you to complete your work while having low cost, toughness and durability that have been tested on site. This is also the mystery of Shenbai Automobile's best-selling. In addition to our truck-mounted trucks and cranes, you can also find wrecker tow trucks, truck cranes, dump trucks, sprinkler trucks, garbage trucks, road sweepers, sewage suction trucks, refrigerated trucks, aerial work trucks, flatbeds Transport vehicles, etc., all of these trucks have the best warranty support in the industry, and the chassis are manufactured by famous brands such as Dongfeng, Cummins, Isuzu, Sinotruk, Shaanxi Automobile, Foton, etc. So, don't ask if you should buy a Shenbai car, but ask why you haven't bought it before. Shenbai Group is committed to recruiting, developing and cultivating first-class talents. Our workforce is large, diverse, and talented. All employees are committed to realizing our core values, doing business with customers easily, and creating a good experience for customers. Today, Shenbai has achieved business diversification in the form of an enterprise group, involved in new fields of construction engineering, road transportation, traffic hoisting, environmental protection, electric power and water conservancy, new energy, and industrial Internet. It will stand out in today's digital world and is also a part of its sustainable solutions, in order to keep moving towards its ultimate goal is to become a world-class enterprise and be able to create real value.

1. We are specialized in the production of truck crane
2. Our factory is the largest manufacturer of truck cranes in China
3. We have a professional research and production team, quality is guaranteed
4.We have their own independent perfect after-sales system, after-sales worry-free

FAQ

1.You are factory or trading Company? Yes, we are oversea sales department of factory. And welcomed to visit our factory.2.Could your company modify the standard product depends on my request? Yes. Our company is specialized in researching and designing various of special purpose vehicle and spare parts. We can provide any product according to your demand. 3. Could your company totally customize products for me? We can provide the customized-designing product meeting with any of your demand. 4. Could you provide certification that we need? We can provide various certifications associate with truck. 5. How long could we receive our goods? It depends on the product that you have ordered. If the goods are prepared, we will deliver your goods as soon as possible. 6. How about the after-sale service? We can provide you the technical support to guide you repaire your product. And we will also send original spare parts if necessory. If you have special need, we can let our engineer to help you.
